360° Omnidirectional High-Torque 2-Axis Expandable Pan-Tilt Camera Module, Driven By Serial Bus Servos, Based On General Driver Board For Robots

WIKI: www.waveshare.com/wiki/2-Axis_Pan-Tilt_Camera_Module

PACKAGE CONTENT

1. 2-Axis Pan-Tilt Camera Module x1
   (* the Raspberry Pi is NOT included)
2. Pi5-Camera-Cable-500mm x1
3. 5.3cm clear suction pad x5
4. 1/4 screw x1
5. Picatinny rail x1
6. Jetson Nano Adapter (A) x1
7. USB Type-A male to Type-C male cable ~1m x1
8. OPTIONS 12V 5A Power supply x1
9. Screwdriver x1
10. 2*5PIN cable ~9cm x1
11. Mini cross wrench sleeve x1
12. Silicone nonskid feet x8
13. Spanner x1

DESCRIPTION

360° Omnidirectional High-Torque 2-Axis Expandable Pan-Tilt Camera Module, Driven By Serial Bus Servos, Based On General Driver Board For Robots, Multiple Expansion Methods, Suitable For Raspberry Pi 4B / 5

360° Omnidirectional High-Torque
2-Axis Pan-Tilt Camera Module

This Is A High-Torque 2-DOF Expandable Pan-Tilt Camera Module, Adopts Serial Bus Servos For Joints Driven. The Horizontal PAN Axis Rotation Range Up To ±180° (360° In Total), The Vertical TILT Axis Rotation Range Up To -45° ~ 90°. Based On The General Driver Board For Robots, Open Source Control Demos For Web APP To Achieve Photo Taking, Video Recording, Face Detection, Motion Detection, Etc. Supports Flexible Expansion And Secondary Development.

* for reference only, the Raspberry Pi 4B is NOT included.

Specifications

Easy To Control Via
Cross-Platform Web Application

Allows Connecting And Controlling The Pan-Tilt Module Via Mobile Phones, Tablets And Computers By Clicking The Buttons On The Web App. Supports Secondary Development Of This Open-Source Web App To Customize The User Interface And Add New Functions.

Flexible 360° Omnidirectional Rotation

The Horizontal Rotation Range Up To 360°, The Vertical Rotation Range Up To 135°

Supports Raspberry Pi 4B / 5

Highly Compatible With Raspberry Pi, Can Be Easily Integrated Into Your Project.

* for reference only, the Raspberry Pi is NOT included.

Open-Source All Demos
For A Variety Of Practical Functions

Face Detection

Motion Detection

Pan-tilt Control

Video Review

160° Ultra Wide-Angle Camera

Comes With 0V5647 5MP 160 Ultra Wide-Angle Camera
Capture Wider Area To Meet Various Visual Requirements

LED Fill Light

Ensures Clear Images In Low-Light Conditions

Small Size × High-Torque

30kg.Cm Ultimate Joint Torque To Meet Various Working Requirements

* for reference only, please refer to the Package Content for detailed part list

Joint Direct-Drive Design With
High-Precision Serial Bus Servos

Adopts Joint Direct-Drive Design With High-Precision Serial Bus Servos, Built In 360° 12-Bit Magnetic Encoder, Supports Obtaining Feedback Information Such As Joint Angle And Joint Load To Realize Closed-Loop Control

Supports Flexible Expansion And Secondary Development

Comes With A Free Picatinny Rail And 1/4 Screw, Open Source For Models And Drawings.
More Convenient For Users To Integrate This Pan-Tilt Camera Module Into Other Projects

* for reference only, please refer to the Package Content for detailed part list

Product Show

* for reference only, please refer to the Package Content for detailed part list

Outline Dimensions
