D435i Real Sense Depth Camera

  • Mã sản phẩm: D435i Real Sense Depth Camera
  • Nhà sản xuất: Intel
  • Website hỗ trợ: https://www.proe.vn
12.500.000₫

The Intel® RealSense™ Depth Camera D400-Series uses stereo vision to calculate depth. The D435 is a USB-powered depth camera and consists of a pair of depth sensors, RGB sensor, and infrared projector. It is ideal for makers and developers to add depth perception capability to their prototype development.

The depth camera includes:

  • A powerful vision processor that uses 28 nanometer (nm) process technology and supports up to 5 MIPI Camera Serial Interface 2 lanes to compute real-time depth images and accelerate output
  • New and advanced stereo depth algorithm for accurate depth perception and long range
  • A set of image sensors that enable capturing of disparity between images up to 1280 x 720 resolution
  • Support for the new cross-platform and open-source Intel® RealSense™ SDK 2.0
  • Dedicated color image signal processor for image adjustments and scaling color data
  • Active infrared projector to illuminate objects to enhance the depth data

Intel® RealSense™ Depth Camera D435 is designed to best fit your prototype. With the global image shutter and wide field of view (91.2° x 65.5° x 100.6°), Intel® RealSense™ Depth Camera D435 offers accurate depth perception when object is moving or device is in motion, and it covers more area, minimizing “blind spots”

For more information regarding Intel® RealSense™ Depth Camera and Intel® RealSense™ technology, go to realsense.intel.com. For latest software releases and to get the Intel® RealSense™ SDK2.0, please visit our GitHub page at: https://github.com/IntelRealSense/librealsense/releases/latest

Use Environment Indoor/Outdoor
Depth Technology Active IR Stereo (Global Shutter)
Main Intel® RealSense™ component

Intel® RealSense™ Vision Processor D4

Intel® RealSense™ module D430

Depth Field of View (FOV)—(Horizontal × Vertical × Diagonal) 85.2° x 58° x 94° (+/- 3°)
Depth Stream Output Resolution Up to 1280 x 720
Depth Stream Output Frame Rate Up to 90 fps
Minimum Depth Distance (Min-Z) 0.2m
Sensor Shutter Type Global shutter
Maximum Range Approx.10 meters; Varies depending on calibration, scene, and lighting condition
RGB Sensor Resolution and Frame Rate 1920 x 1080 at 30 fps
RGB Sensor FOV (Horizontal x Vertical x Diagonal) 69.4° x 42.5° x 77° (+/- 3°)
Camera Dimension (Length x Depth x Height) 90 mm x 25 mm x 25 mm
Connectors USB 3.0 Type - C
Mounting Mechanism

One 1/4-20 UNC thread mounting point

Two M3 thread mounting points

Tech Specs

Datasheet

Features Use environment:
Indoor/Outdoor

Image sensor technology:
Global Shutter
Ideal range:
.3 m to 3 m
Depth Depth technology:
Stereoscopic

Minimum depth distance (Min‑Z) at max resolution:
~28 cm

Depth Accuracy:
<2% at 2 m1
Depth Field of View (FOV):
87° × 58°

Depth output resolution:
Up to 1280 × 720

Depth frame rate:
Up to 90 fps
RGB RGB frame resolution:
1920 × 1080

RGB frame rate:
30 fps

RGB sensor technology:
Rolling Shutter
RGB sensor FOV (H × V):
69° × 42°

RGB sensor resolution:
2 MP
Major Components Camera module:
Intel RealSense Module D430 + RGB Camera
Vision processor board:
Intel RealSense Vision Processor D4
Physical Form factor:
Camera Peripheral

Length × Depth × Height:
90 mm × 25 mm × 25 mm
Connectors:
USB‑C* 3.1 Gen 1*

Mounting mechanism:
– One 1/4‑20 UNC thread mounting point.
– Two M3 thread mounting points.
