JETSON-ORIN-NX-16G-DEV-KIT (US)

Bảo hành 12 tháng : máy, nguồn, wireless và SSD

Jetson Orin NX 16GB Module

• AI Perf: 100 TOPS

• GPU: 1024-core NVIDIA Ampere architecture GPU with 32 Tensor Cores

• CPU: 8-core Arm® Cortex®-A78AE v8.2 64-bit CPU 2MB L2 + 4MB L3

• Memory: 16GB 128-bit LPDDR5 | 102.4GB/s

• Storage: Supports external NVMe

PACKAGE CONTENT

Weight: 0.552 kg

JETSON-ORIN-NX-DEV-KIT

1. Waveshare Orin NX development kit:
   OPTIONS Jetson Orin NX Module x1
   JETSON-ORIN-IO-BASE x1
   Cooling Fan x1
   128GB NVMe Solid State Drive (assembled) x1
   Wireless network card (assembled) x1
2. USB Type A to Micro B cable (~1.2m) x1
3. Ethernet cable (~1.5m) x1
4. Jumper x1
5. OPTIONS Power adapter x1

Jetson Orin NX AI Development Kit For Embedded And Edge Systems, Options For 8GB/16GB Memory Jetson Orin NX Module

JETSON-ORIN-NX-DEV-KIT

Waveshare Jetson Orin NX Dev Kit

Based On Jetson Orin NX Module
AI Edge Computing Development Kit

This Is Not The N-VIDIA Official Developer Kit

Based on Jetson Orin NX Module, with JETSON-ORIN-IO-BASE base board, providing rich peripheral interfaces such as M.2, DP, USB, etc., which is more convenient for users to realize the product performance.

This kit includes the Orin NX Module with options for 8GB/16GB memory, no built-in storage module, provides up to 70 TOPS/100 TOPS AI Performance. Comes with a Free 128 GB NVMe Solid State Drive, high-speed reading/writing, meet the needs of large AI project development.

* for reference only, the actual appearance of the Solid State Drive may be different

This kit also comes with a pre-installed AW-CB375NF wireless network card that supports Bluetooth 5.0 and dual-band WIFI, with two additional PCB antennas, for providing high-speed and reliable wireless network connection and Bluetooth communication.

Kit Selection Guide

JETSON-ORIN-NX-DEV-KIT
Includes Jetson Orin NX Module (options for 8GB/16GB), JETSON-ORIN-IO-BASE base board, Cooling Fan, 128GB NVMe Solid State Drive, AW-CB375NF dual-band wireless network card, USB cable, Ethernet cable, Power supply, etc.

JETSON-ORIN-NX-DEV-KIT-A: Camera kit
On the basis of the JETSON-ORIN-NX-DEV-KIT, it is equipped with an 8MP (3280 x 2464) high-definition camera, suitable for the AI intelligent applications such as face recognition, road sign recognition and license plate recognition.

JETSON-ORIN-NX-DEV-KIT-B: Camera + Touch display kit
On the basis of the Kit A, it is equipped 13.3inch Capacitive Touch Screen LCD (with case), 1920×1080 resolution, up to 10-point touch, built-in ferrite Hi-Fi speaker. It can display the images taken by the camera in real time, to achieve more human-computer interaction of artificial intelligence operations.

Jetson Orin NX Module Specification

Onboard Resources

Professional Application Software And Models

N-VIDIA Software
All N-VIDIA Jetson modules and developer kits are supported by the same N-VIDIA Jetson software stack, so you can develop once and deploy everywhere. Jetson software is designed to provide end-to-end acceleration for AI applications and accelerate the time to market. This brings the powerful N-VIDIA technologies that power data centers and cloud deployments to the edge.

Pretrained Models
Many AI applications have common needs: classification, object detection, language translation, text-to-speech, recommender engines, sentiment analysis, and more. Pretrained models from the NGC™ catalog are performance-optimized and ready to be fine-tuned with the N-VIDIA TAO Toolkit and customer datasets, reducing time and cost for production AI software development.

N-VIDIA Platforms For Robotics, AI Speech, And Smart Cities

N-VIDIA Software Platforms Including Isaac For Robotics, Riva For AI Speech, And Metropolis For Video Analytics, Are Available To Speed Vertical-Specific Applications

N-VIDIA Isaac
Robots improve efficiency and quality of life in industries such as manufacturing, logistics, healthcare, and service. N-VIDIA Isaac™ accelerates the process with enhanced robotics development, simulation, and deployment.

N-VIDIA Riva
N-VIDIA Riva is a fully accelerated SDK for building multimodal conversational AI applications using an end-to-end deep-learning pipeline, suitable for optimized skills in speech, vision, and natural language processing (NLP) tasks.

N-VIDIA Metropolis
N-VIDIA Metropolis includes an application framework, s set of developer tools, and the partner ecosystem. It brings visual data and AI together to improve operational efficiency and safety across a broad range of industries.

Product Show

Outline Dimensions

Resources & Services

Wiki: www.waveshare.com/wiki/JETSON-ORIN-NX-8G-DEV-KIT www.waveshare.com/wiki/JETSON-ORIN-NX-16G-DEV-KIT
