ESP32 PLC 38AR
- Mã sản phẩm: ESP32 PLC 38AR
- Nhà sản xuất: Industrial Shields
- Website hỗ trợ: https://www.proe.vn
19.900.000₫
ESP32 PLC based details
Industrial Automation
Modular PLC
This is the first equipment based on the ESP32 technology designed for a professional use. This PLC has 38 I/Os. It also contains several communication ports which provide more flexibility and control. The ESP32 family offers the possibility to expand up to 127 modules through I2C, which means that you can have until 7100 Inputs / Outputs in Master-Slave connections, additionally to sensors, etc…
Programming Software
This PLC can be programmed using the Arduino IDE platform. See the Documentation menu below to download the software for free.
Instantaneous connection and coding
The ESP32 PLC is programmed through the USB ports. This PLC can also be programed through Ethernet port remotely. This offers and immediate access to program, mantain and control. Also you can continuously monitor the status for all the variables, inputs, outputs, etc. It is compatible with Ardbox and Touchberry Pi devices with instantaneous connection.
Inputs ▼
| Total Inputs | 19 |
| Total Digital Optoisolated Inputs (4-24Vdc) | 9 |
| Digital Optoisolated Inputs (4-24Vdc) | 5 |
| Digital Optoisolated Inputs (4-24Vdc) | can work like interrupt Inputs INT (4-24Vdc) | 4 |
| 11 bit Analog Inputs (0-10V) | Digital (4-24Vdc) Inputs configurable by software | 10 |
Inputs note - * From the (Xx) Digital, (Yx) can be configured as Analog (Xx = Total Digital In, Yx = Number of Analog In) * From the (Xx) Digital, (Zx) can be configured as Interrupt (Xx = Total Digital In, Zx = Number of Interrupt pins)
Outputs ▼
| Total Outputs | 19 |
| Digital Optoisolated Outputs (5-24Vdc) | 5 |
| Digital Optoisolated and PWM (5-24Vdc) | 12 bit Analog (0-10V) Outputs configurable by switch | 6 |
| Relay Outputs (220Vac - 5A) |
Communications ▼
| Ethernet communication | 1 |
| Wi-Fi & BLE (Bluetooth Low Energy) | 1 |
| GPRS/GSM | NO |
| LoRa | NO |
| DALI | NO |
| USB port (type B) communication (for uploading or debugging only) | 0 |
| Micro USB port (type B) communication (for uploading or debugging only) | 1 |
| I2C communication (interface with other Industrial Shields, sensors, I/Os modules) | 1 |
| Serial TTL (UART) communication | 1 |
| RS-232 communication | 1 |
| Half/Full Duplex RS-485 communication | 1 |
| SPI external port communication (using MOSI, MISO, SS pins of Arduino) | 1 |
| RTC (Real Time Clock. NOTE: I2C port used. See pinout modification) | YES |
| µSD Socket (using SPI port, chip select D53 pin) | YES |
Communications notes - * When using I2C, 2 inputs are lost
The Open Source Board CPU ▼
| Single Board Computer (SBC) Microcontroller | ESP32 WROOM 32UE |
| Flash Memory (MB) | 4 |
| SRAM (KB) | 520 |
| SRAM in RTC (KB) | 16 |
| Clock Speed (MHz) |
