Mini-Computer Based on Raspberry Pi Compute Module 4 (NOT Included), Mini IO Board Full Ver, Metal Case, with Cooling Fan

PACKAGE CONTENT

Weight: 0.376 kg

1. CM4-IO-BASE-B x1
2. Metal case (top and bottom) x1
3. Fan-4010-PWM-5V x1
4. 5V 3A USB-C power adapter x1
5. Screwdriver x1
6. Screws pack x1

Mini-Computer Based On Raspberry Pi Compute Module 4 (NOT Included), Mini IO Board Full Ver, Metal Case, With Cooling Fan

Mini-Computer Based On CM4

Designed For Raspberry Pi Compute Module 4

Waveshare CM4-IO-BASE-B (Full Ver.) Inside, Fast And Easy To Build A Mini-Computer

Waveshare Mini IO Board (Full Ver.) Inside

Make It Easy To Build Your Own Raspberry Pi CM4 Mini PC

for reference only, CM4 and antenna are NOT included.

Comparing The Expansion Boards

CM4 IO BOARD	WAVESHARE MINI IO BOARD		WAVESHARE POE IO BOARD (B)	WAVESHARE POE IO BOARD	RASPBERRY PI IO BOARD
	LITE VER.	FULL VER.
POE	N/A		integrates 802.3af-compliant PoE circuit (5V/2.5A)		PoE header only
USB	USB 2.0 × 2 USB 2.0 × 2 (via FFC connector)		USB 2.0 × 4	USB 3.2 Gen1 × 4	USB 2.0 × 2 USB 2.0 × 2 (via pin header)
HEADER	40PIN GPIO × 1 M.2 slot × 1		40PIN GPIO × 1 RS485 × 1 RS232 × 1 standard PCIe Gen 2 × 1	40PIN GPIO × 1	40PIN GPIO × 1 standard PCIe Gen 2 × 1
HDMI	HDMI × 1 HDMI × 1 (via FFC connector) supports 4K 30fps output		HDMI × 2 supports 4K 30fps output
DSI DISPLAY	MIPI DSI display port × 1 (15pin 1.0mm FPC connector)		MIPI DSI display port × 2 (15pin 1.0mm FPC connector)	MIPI DSI display port × 2 (22pin 0.5mm FPC connector)
CSI CAMERA	MIPI CSI-2 camera port × 2 (15pin 1.0mm FPC connector)			MIPI CSI-2 camera port × 2 (22pin 0.5mm FPC connector)
POWER INPUT	5V		5V	7V~36V	12V
FAN	5V		5V / 12V		12V
	no fan control	allows speed adjustment and measurement
RTC	N/A	Real-time clock with battery socket and ability to wake Compute Module 4
ETHERNET	Gigabit Ethernet RJ45
CM4 SOCKET	suitable for all variants of Compute Module 4
SD CARD SLOT	MicroSD card socket for Compute Module 4 Lite (without eMMC) variants
DIMENSIONS (MM)	85.0 × 56.0		124.50 × 108.80	160 × 90

Rich Peripheral Connectors

Onboard Connectors Including
CSI/DSI/RTC/FAN/HDMI/USB/RJ45 Gigabit Ethernet/Micro SD Card Slot/M.2 Slot

Precise Cut-Out With Clear Label

Each Cut-Out Is Completely Aligned With The Connector

Cooling Fan Included

Comes With Cooling Fan, Combined With The Airflow Vent, Better Heat Dissipation

Wall Mount Support

Wall Mount Holes On Two Sides, Handy For Mounting

Application Examples

Binocular Vision Raspberry Pi Projects, Or Other Industrial Context

for reference only, display, cameras, antennas are NOT included.

Outline Dimensions

Resources & Services

WIKI: CM4-IO-BASE-B
