Remote I/O 8-CH Analog Input Module

ADLINK's NuDAM data acquisition modules make up a total acquisition network and control system. Up to 256 NuDAM modules an be romotely controlled on any RS-485 network from a host computer, via a single serial RS-232, allowing communication from as far as 4000 feet from the host. Based on the RS-485 multi-drop network system, each module has a unique address ID, whereby simple ASCII command & response protocols through the standard RS-485 interface can control all the NuDAM modules in the RS-485 network. The NuDAM modules provide direct communications with a wide variety of sensors, perform all signal conditioning, scaling, linearization and conversion, and can acquire measurements of temperature, pressure, flow, voltage, current, and multiple digital signal types.

Key Features

• Channels: 6 Differential & 2 Single-ended
• Input Type: mV, V and mA
• Input Range: ± 150 mV, ± 500 mV, ± 1 V,± 5 V, ± 10 V
• Current Range: ± 20 mA
• Isolation Voltage: 2500 VRMS
