CM5-NANO-A

WIKI: www.waveshare.com/wiki/CM5-NANO-A

Weight: 0.015 kg

1. CM5-NANO-A x1
2. 2*20PIN color-coded straight pinheader x1

1

2

Nano Base Board (A) for Raspberry Pi Compute Module 5, Same Size As The CM5

Nano Base Board (A) for CM5

Suitable For Evaluating The Raspberry Pi CM5 Or Being Integrated Into End Products

Base Board for Compute Module 5 Lite / eMMC

Same Size As The CM5

Compact size and fully functional, With Multiple Peripheral Interfaces, Suitable for Narrow Application Environments

Note: the CM5 is NOT included. Please buy it separately.

Specifications

What's On Board

1. CM5 socket
   suitable for all variants of Compute Module 5
2. USB port
   USB 3.2 Gen1 high speed interface, for connecting sorts of USB devices
3. TF card slot
   for connecting a TF card with pre-burnt image (Lite variant ONLY)
4. Power supply / Programming
   5V power supply, or used for eMMC burning
5. FAN header
   4PIN JST-SH PWM fan header for connecting a cooling fan
6. PSW button
   power button
7. BOOT button
   Press before powering on and release after powering on to enter the burning mode

8. 2PIN JST-SH RTC battery header
9. 40PIN GPIO interface
   suitable for connecting to various HAT modules
10. Dual MIPI interfaces
    for connecting to DSI displays or CSI cameras
11. Special function pins
    CM5 core power enable and ETH SYNC signal
12. IO-VREF selection
    CM5 IO logic level: 3.3V or 1.8V
13. Function enable pins
    Enabled by default, can be disabled by shorting the corresponding pads
14. Dual-color LED indicator
    Red light: Raspberry Pi power indicator
    Green light: Raspberry Pi working status indicator

Outline dimensions

About Compute Module 5

Newly upgraded, more powerful

• Upgraded processor BCM2712, quad-core Cortex-A76 64-bit SoC, more powerful performance
• More options for RAM (2GB / 4GB / 8GB / 16GB)
• More options for eMMC Flash (0GB (Lite) / 8GB / 16GB / 32GB / 64GB)
• Faster eMMC Flash storage, up to 200 Mbps data rate
• Optional for certified radio module, supports either PCB trace antenna or external antenna, more suitable for industrial applications
• Adopts B to B connectors, most compatible with Compute Module 4
• Onboard Gigabit Ethernet PHY supporting IEEE1588, suitable for network applications
• Onboard PCIe Gen 2 x1 interface, allows connecting more useful modules
